| Specification |
| • Dimensions : |
57mm [ L ] - 7.7mm [ H ] - 12.56mm [ W ] |
| • Weight : |
5 g |
| • IC : |
RTS 5169 |
| • Power supply : |
DC + 5V Built-in 3.3v regulator for single 5v operation |
| • Operating temperature : |
0° - 70° C |
| • Operating humidity : |
20 - 95 % |
| • Host Interface Serial : |
USB 2.0 CCID (also compliant with USB 1.1) |
| • Plug & Play : |
CCID compliant for easy plug & play |
| |
(No additional USB driver is required of operating systems supports CCID) |
| • Transmission speed : |
12 Mbps (USB 2.0 full speed) 115,200 kbps (serial) |
| • Standards : |
ISO 7816 & EMV 2000 ver.4.1 Level 1 |
| • Protocols : |
T = 0, T = 1 2-wire SLE 4432/42 (S=10) |
| |
3-wire SLE 4418/28 (S=9) I2C (S=8) |
| • Smart Card Interface speed : |
420 Kbps (when supported by card) |
| • Smart Card clock frequency : |
Up to 8 MHz |
| • Supported Card types : |
5V, 3V and 1.8V |
| • Smart Cards : |
ISO7816 Class A, AB and C |
| • Card size : |
ID-1 (full-size) |
| • Card Thickness : |
0.76 mm ± 0.08 mm |
| • Power to Smart Card : |
60mA |
| • Power consumption : |
Power on 100mA max, Short circuit protection |
| • Smart card contact |
0.5 Ohm max between two line |
| resistance : |
|
| • Ripple : |
100 mVp-p max |
| • Smart card detection : |
Movement Detection with auto power-off Automatic |
| |
Detection of Smart Card type Short Circuit and thermal protection |
| • 8 Pin Handling : |
C4 / C8 supported |
| • Supported APIs : |
PC/SC driver (ready for 2.01)CT-API |
| |
(on top of C/SC)Synchronous-API (on top of PC/SC)OCF (on top of C/SC) I2C (on top of PC/SC) |
| • PC/SC Driver Support : |
XP SP3 32/64 Bit 2003 Server |
| |
Windows® CE 5.0 / CE NET (depending on hardware) Windows® Vista (32 /64 bit), Windows® 8 Mac® OS X (Power PC / Intel) Linux® |
| • Drivers : |
CCID-compliant ( Mac® OS X, Windows®, Linux® ) |
| • Status indicator : |
1 led indicator (WHITE) |
| • Compliance / Certification : |
Certification Microsoft® |
| |
WHQL EMV 2000 Level 1 ISO 7816 USB 2.0 (USB 1.1 compatible) CCID |
| • Safety / Environmental |
FCC, CE, ROHS |
| |
|
| |
