Scanning Type

Color CCD (Simplex)

Optical Resolution

600 Dpi

Hardware Resolution

Flatbed

600 Dpi x 600 Dpi

ADF

600 Dpi x 600 Dpi

Scan Modes

Color : Input 48-bit; Output 24-bit
Grayscale : Input 16-bit; Output 8-bit
Black & White : 1-bit

ADF

Feeder Capacity

80 sheets (A4/ Letter, 70 g/m2 or 18 Lbs)

Scanning Speed

75 ppm @ 200 dpi, A4, grayscale mode

Scanning Area

Max. 216x356 mm (8.5”x14”)
Min. 12.7x12.7 mm (0.5”x0.5”)

Acceptable Paper Size

Max. 220x356 mm (8.66”x14”)
Min. 90x114 mm (3.55”x4.5”)

Acceptable Paper Weight

50 to 120 g/m2 (14 to 32 Lbs)

Flatbed

Scanning Area

Max. 216x297 mm (8.5”x11.69”)
Min. 12.7x12.7 mm (0.5”x0.5”)

Acceptable Paper Size

Up to A4/ Letter size (8.5”x11.69”)

Action Button

OCR, File, Scan, Copy, Email, Custom 1, Custom 2

Power Supply

Input Volage:100~240V/ Output Voltage:24V, 1.67A

Environment Requirement

WEEE/ROHS

Interface

USB 2.0

Net Weight

5.5 kg (12.1 Lbs)

Dimension (WXDXH)

W/O Input Tray

468 x 341.5 x 195 mm (18.43”x13.44”x7.68”)

With Input Tray

468 x 341.5 x 320 mm (18.43”x13.44”x12.60”)

Protocol

TWAIN Compliant

OS

Windows 2000, XP, Vista, 7
